UP3D IronCore i5 Pro

The UP3D IronCore i5 Pro Wet/Dry Milling Machine is a heavy-duty 5-axis dental milling system engineered for precise, efficient production across a wide range of restorative and implant applications. Built on a one-piece solid cast-iron frame with a powerful 2.5 kW water-cooled spindle, the IronCore i5 Pro provides the rigidity and stability required for demanding metal milling while supporting both wet and dry workflows for greater laboratory versatility.

Designed to bring more production in-house, the UP3D IronCore i5 Pro Wet/Dry Milling Machine supports titanium, zirconia, glass ceramics, PMMA, PEEK, composite resin, wax, and pre-milled blanks. Its 18-tool automatic tool changer, smart servo technology, automatic calibration, integrated coolant management, and 15-inch touchscreen help simplify daily operation while maintaining consistent milling performance across everything from crowns and veneers to custom abutments, implant bars, and full-arch frameworks.

Advantages

• Heavy-duty 5-axis milling: A solid cast-iron frame, smart servo technology, and 2.5 kW water-cooled spindle provide the stability and cutting power needed for demanding restorative and implant workflows.

• Wet and dry versatility: Supports a broad range of materials, including titanium, zirconia, glass ceramics, PMMA, PEEK, composite resin, wax, and pre-milled blanks, allowing laboratories to complete more cases on a single platform.

• Automated laboratory workflow: An 18-tool automatic tool changer, tool measurement and breakage monitoring, one-click calibration, integrated coolant management, and intuitive touchscreen controls help reduce manual intervention and streamline production.

Technical Parameters

Product Type: 5-axis wet/dry dental milling machine

Applications: Anatomical crowns, bridges, screw-retained crowns, inlays, onlays, veneers, custom abutments, bars, angled abutments, implant-supported frameworks, and other dental restorations

Milling Modes: Wet and dry milling

Compatible Materials: Titanium, zirconia, glass ceramics, PMMA, PEEK, composite resin, wax, and pre-milled blanks

Number of Axes: 5-axis

A-Axis Rotation: ±360°

B-Axis Rotation: ±30°

Machine Construction: One-piece solid cast-iron frame

Spindle Type: High-frequency, water-cooled electric spindle with pneumatic tool change

Maximum Spindle Speed: 60,000 rpm

Spindle Power: 2.5 kW

Tool Capacity: 18 tools with automatic tool changing

Tool Holding: 6.0 mm

Material Capacity: Discs up to 98.5 mm in diameter and 10–30 mm thick; blocks up to 40 × 20 × 20 mm

User Interface: 15-inch touchscreen

Calibration: One-click automatic calibration

Monitoring: Built-in HD camera with tool length measurement and tool breakage monitoring

Connectivity: Wi-Fi, USB, and Ethernet

CAM Software: UPCAM and MillBox compatible

Compressed Air Requirement: 0.6–0.9 MPa, 80 L/min

Power Supply: 220V AC, 50–60 Hz

Rated Power: 5.5 kW

Dimensions: 660 × 680 × 1750 mm

Weight: 480 kg

Operating Temperature: 10–35°C

Operating Humidity: Below 80% RH, non-condensing

Ideal Users: Dental laboratories, implant laboratories, full-arch production facilities, restorative laboratories, and high-volume digital dental production facilities.
