VITA ZYRCOMAT® 6100 MS
The VITA ZYRCOMAT® 6100 MS is a premium high-temperature zirconia sintering furnace designed to deliver fast, precise, and reliable sintering for modern dental laboratories. Manufactured in Germany, the furnace supports HighSpeed, conventional, and user-defined sintering programs, allowing technicians to select the ideal cycle for each case. Its advanced heating system provides exceptional temperature accuracy and uniform heat distribution, ensuring consistently strong, esthetic zirconia restorations.
Designed to integrate seamlessly into digital workflows, the VITA ZYRCOMAT® 6100 MS features automatic temperature calibration before every firing cycle, controlled cooling for stress-free restorations, and intelligent monitoring functions that maximize reliability. The furnace accommodates both VITA zirconia materials and other commercially available zirconia and aluminum oxide ceramics, making it a versatile solution for laboratories seeking efficiency, flexibility, and outstanding restorative results.
Advantages
• Multiple sintering modes: HighSpeed, conventional, and customizable programs provide the flexibility to meet a wide range of restorative requirements while reducing turnaround times.
• Exceptional accuracy: Automatic temperature calibration, four high-performance heating elements, and uniform heat distribution ensure predictable, high-quality sintering results.
• Reliable long-term performance: Intelligent monitoring functions, controlled cooling, and an energy-efficient design help extend component life while maintaining consistent performance.
Technical Parameters
Product Type: High-temperature zirconia sintering furnace
Applications: Zirconia crowns, bridges, implant restorations, full-arch prostheses, copings, and aluminum oxide ceramic frameworks
Compatible Materials: Zirconia (ZrO₂) and aluminum oxide (Al₂O₃) dental framework materials
Sintering Modes: HighSpeed, conventional, and user-defined
Maximum Temperature: 1,600°C
Heating Elements: Four molybdenum disilicide heating elements
Temperature Accuracy: ±2°C
Calibration: Automatic temperature adjustment before each program
Cooling: Controlled cooling to reduce stress in restorations
Sintering Chamber Diameter: 90 mm (usable)
Sintering Chamber Height: 70 mm (usable)
Power Supply: 230V AC, 50/60 Hz
Power Consumption: Maximum 1.5 kW
Dimensions: 315 × 500 × 470 mm
Weight: 34.8 kg
Control System: Compatible with VITA vPad LITE and VITA vPad PRO
Ideal Users: Dental laboratories, milling centers, and high-volume digital dental production facilities
